Darkglass Alpha Omega 200 bassovahvistin
Darkglass Alpha·Omega 200 – yli 200 wattia isoa soundia pienessä koossa!
The compactness and lightweight make them flawless and convenient for rehearsals and live gigs, while an EQ section enhances the definition and clarity of sound across the spectrum.
Front Panel Features
Use this jack to connect your instrument via a standard ¼” mono cable.
This knob controls the amount of distortion that the Alpha • Omega Engine will deliver. It will cover a wide range of overdriven tones from subtle break up to overly distorted sounds.
Selects or mixes between the two distinct distortion circuits: Alpha is punchy, tight with a lot of definition, whereas Omega is simply brutal and raw.
Use this knob to mix between the Clean signal and the Distortion signal (Alpha • Omega Engine).
+-12dB at 80Hz. Use this knob to change the low-end content of the signal.
+-12dB at 1kHz. This knob controls the mid content of the signal.
+-12dB at 5kHz. Use this knob to change the high content of the signal.
Use this knob to control the overall volume of the amplifier. Use this push knob button to mute the amplifier.
150x52x157 mm (5.9x2.04x6.18 in)
There are no user-serviceable parts inside the amplifier. Do not open the amp.
Never use the amp in a high moisture environment or near liquids.
The Alpha·Omega 200 can deliver more than 100 dB of power. Exposure to this level of sound can damage your hearing. Always use proper hearing protection when exposed.
The Alpha·Omega 200 can deliver more than 200 watts. Be sure that your speaker cabinet is able to deliver that power.
Do not cover the vent holes. The fan and vent holes are part of the cooling system of the amp. Covering the vent holes can lead to overheating and damage to the amplifier.
Do not use an instrument cable as speaker cable. An instrument cable is not designed to deliver the type of power sent from the amplifier to the speaker.
Back Panel Features
Use this connector to connect the amplifier to your cabinet. This Speakon combo jack allows for either Speakon or ¼” speaker cable operation. WARNING: Do not use an instrument cable with this jack. Using an instrument cable can damage your amplifier. Minimum load 3Ω.
Use this control to lift the ground of the DI XLR output. If you are experiencing ground noise in your DI signal try changing the setting of this control.
Use this connector to send your bypass signal to the console, mic preamp, interface, etc. The DI OUTPUT delivers only the bypass DI signal.
Connect your Headphones and enjoy the analog cabinet emulation.
Use this connector to play music from your laptop, phone, MP3 player, etc. This input is routed only to the headphone output without cabinet emulation.
Use this connector to feed electric power to the amplifier. 100 - 230 VAC, 50-60Hz.
AC Power ON/OFF
Use this Switch to release the audio energy from your bass.
